Propel Advanced SL-FF

/ GIANT

Propel Advanced SL-FF

SKU: 1906011203
$5,499.00
Sale price  $5,499.00 Regular price

RIDE NOW PAY LATER- Finance options with ZIP MONEY,Studio 19 Rental &Total Lifestyle Credit.
*Not available on some discounted items. Fees may apply.

Size
ColourAurora Chameleon
Out of stock

Specifications

From breakaways to the final sprint. On flat roads, climbs or descents. The reengineered Propel Advanced SL cuts through wind and maximises watts, optimising your energy through every dimension of speed: top-end speed, instant speed and sustained speed.

Key Performance Factors

INSTANT SPEED

In the moments when explosive speed matters most—launching an attack, chasing a break, or sprinting for the finish line—the new Propel Advanced SL is quicker and more dynamic than ever. The new frameset is more efficient with 14.2% more torsional stiffness and 14.8% greater pedalling stiffness—so you feel instantaneous reaction when you make your move.

SUSTAINED SPEED

Engineered for full-bike compliance, the new Propel Advanced SL frameset delivers a significantly smoother ride when you’re rolling in the group or piling up training miles. The Vector integrated seatpost has 25% greater compliance compared to the previous generation. The fork helps absorb bumps and vibrations up front. And additional tyre clearance allows for high-volume tyres up to 32mm, further smoothing out the ride to help you maintain higher speeds with less fatigue.

TOP-END SPEED

The frameset, including the frame, fork, Vector integrated seatpost, and aero bottle cages, are designed to be part of a system to lower total resistance when you’re pushing high speeds in the wind—whether you’re on a solo break, taking pulls at the front, or powering away on a climb. OverDrive Aero technology includes a slim, tapered head tube paired seamlessly with a D-shaped fork steerer tube and spacers. Brake and shifter cables can be internally routed through the frame and fork, keeping them hidden from the wind.

Highlights

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorised dealer to determine the correct size.
Available sizes may vary from country to country.

bike diagram with measurements referenced in table that follows

  XS S M M/L L XL
A Seat Tube Length (mm) 484 505 528.5 554 576 595
B Seat Tube Angle 74.5° 74.0° 73.5° 73.0° 73.0° 72.5°
C Top Tube Length (mm) 520 535 550 565 580 600
D Head Tube Length (mm) 115 127 145 165 185 200
E Head Tube Angle 71.5° 72.5° 73.0° 73.0° 73.0° 73.0°
F Fork Rake (mm) 45 45 45 45 45 45
G Trail (mm) 67.8 61.4 58.3 58.3 58.3 58.3
H Wheelbase (mm) 971 973 980 990 1006 1020
I Chain Stay Length (mm) 405 405 405 405 405 405
J Bottom Bracket Drop (mm) 72 72 69.5 69.5 67 67
K Stack (mm) 515 530 546 565 582 596
L Reach (mm) 377 383 388 392 402 412
M Stand Over Height (mm) 746 764 787 808 832 847
O Stem Length (mm) 80 90 100 110 110 120
P Crank Length (mm) 165 165 170 170 172.5 172.5
Q Wheel Size 700C 700C 700C 700C 700C 700C
Specs
  • Sizes
    XS, S, M, M/L, L, XL
  • Colours
    Aurora Chameleon, Cyber Sunset
  • Frame
    Advanced SL-grade Composite, 12x142mm thru-axle, UDH compatible, integrated seatpost, disc
  • Fork
    Advanced SL-grade composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
  • Seatpost
    Advanced SL-grade composite, integrated design, -5/+15mm offset
  • Bottom Bracket
    BB86 accepts press fit style BB only, bearing set not included
  • Extras
    Front & rear 12mm thru-axles, 20mm & 45mm ISP clamps, Bottle Cages, 32mm max tyre size
  • Max Tyre Clearance
    32mm
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
