Trinity Advanced SL 2

/ GIANT

Trinity Advanced SL 2

SKU: 9138008103
$8,999.00
Sale price  $8,999.00 Regular price

RIDE NOW PAY LATER- Finance options with ZIP MONEY,Studio 19 Rental &Total Lifestyle Credit.
*Not available on some discounted items. Fees may apply.

Size
ColourCarbon/Pearl Teal
Out of stock

Specifications

From windswept flats to climbs, corners and descents, the new Trinity Advanced SL delivers dynamic speed and control when every second counts. Easily adaptable to triathlon or TT, and featuring aero-integrated hydration and fuelling systems, it's lighter, more aerodynamic and smoother riding than the previous generation, with greater adjustability to dial in position and fit.



Key Performance Factors



Full-speed dynamics

All-new composite frameset designed for flat-out speed and pinpoint control when racing against the clock. Lighter weight for faster climbing, integrated disc brakes for confident cornering and descending, added compliance for smoother ride performance, plus an integrated bento box and hydration straw to help riders produce full power without disturbing their riding position.

Ultimate aero efficiency

AeroSystem Shaping Technology with truncated ellipse tubing for a 5.9-watt aero advantage and greater stiffness-to-weight ratio over the previous generation Trinity. In addition, the hydration reservoir, bottles and bento box form an aero-optimised, integrated fuelling system.

Personalised fit

With a far greater range of adjustability compared to previous Trinity models—including three seatpost offset positions (51mm range) and 24x more armrest positioning options (stack, reach, angle and width)—it's easier than ever to dial in fit for all body types and any riding position using simple two-bolt mechanisms.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorised dealer to determine the correct size.
Available sizes may vary from country to country.

bike diagram with measurements referenced in table that follows

  XS S M L
A Seat Tube Length (mm) 477 508 538 565
B Seat Tube Angle 77.0° 77.0° 77.0° 77.0°
C Top Tube Length (mm) 510 530 554 579
D Head Tube Length (mm) 85 105 125 145
E Head Tube Angle 72.0° 73.0° 73.0° 73.0°
F Fork Rake (mm) 40 40 40 40
G Trail (mm) 69 63 63 63
H Wheelbase (mm) 974 988 1013 1039
I Chain Stay Length (mm) 405 405 405 405
J Bottom Bracket Drop (mm) 70 70 70 70
K Stack (mm) 490 513 532 551
L Reach (mm) 397 412 432 452
M Stand Over Height (mm) 758 786 814 838
P Crank Length (mm) 160 165 170 172.5
Q Wheel Size 700C 700C 700C 700C
R Arm Pad Stack (TRI) 629-709 | (TT) 582-662 (TRI) 653-733 | (TT) 605-685 (TRI) 672-752 | (TT) 624-704 (TRI) 691-771 | (TT) 643-723
S Arm Pad Reach (TRI) 323-398 | (TT) 339-414 (TRI) 340-415 | (TT) 355-430 (TRI) 360-435 | (TT) 375-450 (TRI) 380-455 | (TT) 395-470
V Pad Reach Min (mm) 323 338 358 378
W Pad Reach Max (mm) 398 413 433 453
Specs
  • Sizes
    XS, S, M, L
  • Colours
    Carbon/Pearl Teal
  • Frame
    Advanced SL-grade composite, 12x142mm thru-axle, disc
  • Fork
    Advanced SL-grade composite, full-composite steerer, 12x100mm, disc
  • Handlebar
    AeroDrive base bar with Sync armrest set, 10 and 15-degree extension wedge
  • Grips
    Rubber integrated
  • Stem
    AeroDrive integrated stem
  • Seatpost
    Trinity Composite
  • Saddle
    Giant Contact SL Tri
  • Shifters
    SRAM eTap AXS Wireless Blips - extension and basebar mounted
  • Front Derailleur
    SRAM Rival AXS, FD-Rival-E-E1
  • Rear Derailleur
    SRAM Rival AXS, RD-Rival-E-E1
  • Brakes
    SRAM Rival AXS HRD, ED-Rival-AERO-E1, SRAM PaceLine X rotors [F]160mm, [R]160mm
  • Brake Levers
    SRAM Rival AXS HRD, ED-Rival-AERO-E1
  • Cassette
    SRAM Rival E1 XG-1250, 12-speed, 10-36
  • Chain
    SRAM Rival-E1, 12-speed
  • Crankset
    SRAM Rival E1 DUB, 35/48 with SRAM spindle power meter XS:160mm, S:165mm, M:170mm, L:172.5mm
  • Bottom Bracket
    SRAM DUB, press fit
  • Rims
    Giant SLR 2 50 WheelSystem, [F]50mm, [R]50mm
  • Hubs
    [F] Giant Alloy, CenterLock, 12mm thru-axle [R] Giant Alloy, 3 pawl 30t driver, CenterLock, 12mm thru-axle
  • Spokes
    SAPIM Sprint
  • Tyres
    CADEX Aero, tubeless, 700x28c (28mm), folding
  • Extras
    Bento box top tube storage, hydration kit, UCI Bottle, Cockpit bottle mount, computer mount, tubeless prepared
  • Max Tyre Clearance
    30mm
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
